| 起源の場所: | 中国 |
|---|---|
| ブランド名: | PRINTYOUNG |
| 証明: | CE |
| モデル番号: | PRY-650A |
| 最小注文数量: | 1セット |
| 価格: | USD 1000 Set |
| 受渡し時間: | 30営業日 |
| 支払条件: | L/C、T/T |
| 供給の能力: | 月額30セット |
| カウントモード: | 逆カウント | 表示モード: | 7インチLCDスクリーン |
|---|---|---|---|
| 最大フィードサイズ: | 330*1000mm | 最小送りサイズ: | 135*135mm |
| ペーパータイプ: | 書き込み、両面糊、コート紙 | 供給モード: | 吸引自動給紙 |
| 供給の方向: | 右側で食事をする | 自動給紙トレイのセット: | 70 mm |
| くぼみ幅ギャップ: | 0.9mm | くぼみの方向: | ポジティブとネガティブの両方 |
| 精度: | ±0.2 mm | 押し込み速度: | 1時間あたり4500部 |
|
Machine Appearance
|
metal , desktop + bottom cabinet
|
|
Machine Speed
|
2 speed option
|
|
Free Indentation
|
√
|
|
Cover Indentation
|
√
|
|
Equipartition Indentation
|
√
|
|
Counting Mode
|
counting reverse counting
|
|
Display Mode
|
7 inch LCD screen
|
|
Maximum Feed Size
|
330 * 1000 mm
|
|
Minimum Feed Size
|
135 * 135 mm (45 * 90 mm optional)
|
|
The Indentation Knife Adapts to the Weight/Thickness of the Paper
|
70 ~ 400 g
|
|
Line Cutter Adapts to Paper Weight/Thickness
|
70 ~ 300 g
|
|
Paper Type
|
writing , double glue , coated paper
|
|
Feed Mode
|
suction automatic paper feed
|
|
Feed Direction
|
feed on the right side
|
|
Feed Table Lengthened
|
√
|
|
Automatic Feed Tray Load
|
70 mm
|
|
The Amount of Paper on the Receiving Tray
|
50 mm
|
|
Indentation Width Gap
|
0.9 mm (0.6 optional)
|
|
Indentation Direction
|
both positive and negative
|
|
Indentation/Precision
|
± 0.2 mm
|
|
Distance between the First Mark and the End of the Paper
|
1 mm
|
|
Indentation Speed (A4 One Mark)
|
4500 copies per hour
|
|
The Maximum Number ofIndentations or Dotted Lines Can be Set
|
32 channels
|
|
Input Power
|
220V / 50Hz
|
|
Machine Power
|
360 W
|
|
Machine Net Weight
|
82kg (with bottom cabinet)
|
|
Weight of Machine After Packing Net
|
98kg (with bottom cabinet)
|
|
Machine Dimensions
|
1490 * 600 * 466 mm
|
|
Dimensions of the Outer Package of the Machine
|
730 * 690 * 750 mm
|
